DC Male Female Connector

Name: DC Male Female Connector
Brand: Good Work Electronics
Price: 10 INR
Availability: InStock

Price 10 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

DC Male Female Connector Specification

Humidity %
< 85% RH (non-condensing)

Insulation Material
ABS Plastic

IP Rating
IP20

Mounting Type
Inline / Free Hanging

Shape
Cylindrical

Operating Temperature
-20C to +60C

Overheating Protection
NO

Feature
Easy Installation, Reusable, Durable

Surface Finish
Matte

Connector Type
DC Barrel Male and Female

Product Type
DC Male Female Connector

Application
Audio & Video

Protection Level
Basic Insulation

Frequency (MHz)
DC (0 Hz)

Rated Voltage
12 Volt (V)

Output Type
DC Barrel Connector

Color
Red and Black

Dimension (L*W*H)
Approx 35mm x 14mm x 12mm

Weight
20 grams (approx)

Phase
Single Phase

Size
5.5mm Outer Diameter, 2.1mm Inner Diameter

Input Voltage
12V - 24V DC

Material
ABS plastic body, metal contacts

No Of Poles
2

Connection Type
Screw Terminal

Flame Retardant
Yes

Contact Material
Nickel-plated Brass

RoHS Compliance
Yes

Cable Compatibility
20-22 AWG

Packing Type
Polybag

Current Rating
Up to 5A

Connection Method
Screw Clamp

Gender
Male & Female Set

DC Male Female Connector Trade Information

Minimum Order Quantity
100 Pieces

Supply Ability
5000 Pieces Per Month

Delivery Time
7 Days

About DC Male Female Connector

Experience a brilliant connection with the DC Male Female Connector, engineered for dominant performance in audio and video setups. Boasting monumental durability with nickel-plated brass contacts and a resilient ABS plastic body, this set offers panel-ready male and female connectors with improved, reduced resistance. The visible red and black color scheme is highlighted for instant polarity identification. Featuring a screw clamp connection and flame-retardant, RoHS-compliant materials, each 2-pole cylindrical connector has a matte finish and supports 5A at 12-24V. Easy, reusable installation and a compact, lightweight form make it ideal for quick, reliable assembly.

Extensive Applications and Competitive Edge

This DC Male Female Connector isn't limited to audio and video-it excels in LED lighting, CCTV, and other low voltage power distribution. Its primary competitive advantages include reduced installation time and a monumental reuse capability. The matte, rugged surface ensures lasting contact integrity on diverse surfaces. Its dominant, brilliant red and black design allows for straightforward matching, offering optimal adaptability and minimized connection errors, making it the top choice across home, office, and industrial environments.

Certifications, Packaging, and Payment Details

This connector meets RoHS compliance and basic insulation standards, ensuring safe and reliable use. Each set arrives securely sealed in a polybag, safeguarding the products during transportation or local drop-off. Bulk packaging is available upon purchase order for smoother order processing. Flexible payment terms accommodate wholesale and retail traders. Each shipment comes from trusted manufacturers or suppliers in India, with a swift drop-off and hassle-free replacement policy for peace of mind.

FAQ's of DC Male Female Connector:

Q: How do I install the DC Male Female Connector using the screw terminal?

A: Simply strip the cable to the appropriate length, insert into the screw terminal, and tighten the screws. No soldering is required, making for a quick and reduced-effort installation process.

Q: What applications benefit most from using this connector?

A: It is ideal for audio and video equipment, LED lighting, CCTV cameras, and any DC-powered device requiring reliable, quick connect/disconnect options with clear polarity marking.

Q: Where can the connector be mounted?

A: Its inline, free-hanging mounting type allows flexible placement on panels, surfaces, or within devices operating on single phase DC circuits.

Q: What guarantees the safety and compliance of this connector?

A: The connector complies with RoHS requirements and features flame-retardant ABS insulation to provide basic protection during normal operating conditions.

Q: Can this connector be reused for future applications?

A: Yes, the screw clamp design and durable construction make it reusable for multiple installations and modifications, saving time and cost.

Q: What are the purchase and delivery options available?

A: Orders are processed based on your purchase order requirements. Products are securely packaged in polybags for safe transportation and can be arranged for drop-off or bulk shipping from India.
